Place of origin: Shandong, China Size: 1220x2440mm, 1250x2500 or customized dimension Glue: phenolic WBP Core: birch Film: dynea film, Chinese film Color: brown/black |
TECHNICAL SPECIFICATION |
Sr No. | Property | Unit | Test Method | Value of Test | Result | |
1. | Moisture Content | % | EN322 | 7.8 | Check out | |
2. | Density | Kg/m3 | EN323 | 690 | Check out | |
3. | Bonding Quality | Bonding Quality | Mpa | EN314 | Max:1.85 Min: 0.99 | Check out |
Damage Rate | % | 94% | Check out | |||
4. | Bending Modulus of Elasticity | Longitudinal | Mpa | EN310 | 9610 | Check out |
Lateral | 7360 | Check out | ||||
5. | Bending Strength N/mm | Longitudinal | Mpa | 79 | Check out | |
Lateral | 77.3 | Check out | ||||
Cycle life: 30-50 repeated using times according to projects by formwork system | ||||||
Birch core is the highest quality raw materials for film faced plywood. Advantages of film faced plywood: 1.Easy To Cut: the plywood is easy to cut, so according to the construction, the formwork could be cut into the required size. 2. Re-used: phenolic film faced plywood could be used 30-50 times. 3. Multi Using: film faced plywood could be used for wall, slab, column, beam and bridge concrete pouring etc.. 4. No Deformation: film faced plywood is also whole but not deformation and chipping after 72 hours cooking in boiling water. 5. High Quality Film: film faced plywood is filmed by Dynea brown or black film imported from Finland, it protect the formwork surface from the corrosion and makes the formwork durable, improves the flatness of the concrete surface and makes the concrete surface save the second time plastering, so it could save a lot cost of construction. |
 |
